Configuring interfaces to the central BMS
List of data points
nviApplicMode
SNVT_hvac_mode
Function: Operating mode default setting
LON Identifier
HVAC_NUL
HVAC_NIGHT_PURGE
nviMode
SNVT_occupancy
Function: Operating mode default setting by central BMS
LON value
0
1
2
3
255
nviOccSensor
SNVT_occupancy
Function: Operating mode default setting by a PIR sensor (by others)
LON value
0
1
2
3
255
42
BACnet
1
6
Identifier
OC_OCCUPIED
OC_UNOCCUPIED
OC_BYPASS
OC_STANDBY
OC_NUL
Identifier BACnet
value
OC_
OCCUPIED
OC_
UNOCCUPIED
OC_ BYPASS
OC_STANDBY
OC_ NUL
C:\Users\SCHMITHUESEN\Desktop\170321_Datenpunkte XAC_EN.docx
Single room control system FSL‑CONTROL II
Modbus
(Register 0)
255
4
BACnet Modbus
value value
(Register 1)
1 0
2 1
3 2
4 3
5 255
Modbus
value
(Register 2)
1 0
2 1
3 2
4 3
5 255
He, 21 March 2017
Description
Invalid = inactive
Night purge
activation
Description
Occupied
Unoccupied
Boost
Standby
invalid
Description
Occupied
Unoccupied
Boost
Standby
invalid
2
