Programmer Manual
Serial Interface Signals
The following table lists the RS-232/C serial interface signals:
Signal Name Pin Number
SIGNAL 5
GROUND
TXD 3
RXD 2
RTS 7
CTS 8
DSR 6
DCD 1
2nd RTS 9
DTR 4

LAN Interface Port

LAN Interface Port
1. Ethernet 10/100BaseT Connector
2. Green 10/100Mbit/sec. Transmission Speed LED
3. Yellow Traffic LED
LED Indicators
The LED indicator modes are described in the following table:
LED Status
Yellow LED Unlit
Lit
Green LED Blinks
USB Interface Port
USB 2.0 full speed 12/Mbit/sec. interface.
Appendix B‐ Interfaces
Local Remote
Connect. Connect.
Source Source
– –
Printer Printer
Host Data Set
Printer Printer
Data Set
Data Set
Data Set
Printer
Printer Printer
Description
Transmission speed at 10Mbit/sec.
Transmission speed at 100Mbit/sec.
Transmitting or receiving packets from the network.
370
Description
Always connected to the 0 Volts of the
Power Supply
Transmitted Data Signal (an output from
printer). A MARK condition is held during
IDLE communication state. An indeterminate
state is present when printer is powered off.
Received data signal (an input to printer).
Request to Send Signal (an output from
printer). Active HIGH level signal. It is HIGH
until the printer is powered off, then an
indeterminate state is present .
Active HIGH level signal indicates that the
host or data set is ready to receive data from
the printer.
Active HIGH level signal. Indicates that the
host or data set is ready to be connected to
the printer and is ready for data transfer.
Active HIGH level signal. Indicates that the
host is transmitting or the data set is r
receiving the Data Carrier signal.
Functionally equivalent to the DTR signal.
Data Terminal Ready. Normally HIGH (ON).
Indicates that the printer is ready to initiate a
connection.
