Notes:
1. If the entire resource list does not fit in the Special Data Area of the Acknowledge Reply, continuation is
necessary which the S828 Printer will indicate using the Acknowledgement Continuation bit in the flag byte of
the Acknowledge Reply. If the host requests Acknowledgement Continuation by sending a command with
ARQ bit and the Continuation bit set, the printer will complete the RRL reply using Acknowledgement
Continuation. If the host requests RRL continuation (by sending an RRL command with nonzero values in
bytes 3 and 4), the printer will use continuation, the printer will default to RRL continuation.
2. For overlays, segments, and symbol sets, this is their two byte ID. This field is omitted when the resource
type equals All.
Acknowledge Reply for Request Resource List
Length D6FF
The format of the resource list returned with the Acknowledge Reply is as follows:
Decimal Hex
0 0
1 1
2 2
3 3
4 4
5-6 5-6
Note: Bytes 2 - 6 repeat for each resource type.
Exception Handling Control (EHC)
An exception (error) exists when the printer detects an invalid or unsupported command, control, or
parameter value in the data stream received from the host. The IPDS structure provides Alternate
Exception Action (AEA) when the printer receives a valid parameter value, but the printer does not support
this value. The Exception Handling Control subcommand allows the host control of exception handling by
the printer. This subcommand specifies the action the printer is to take with respect to the reporting and
processing of exception (error) conditions. The format of the EHC subcommand is:
Decimal Hex
0-1 0-1
Chapter 5 IPDS Programming Information
Flag Correlation ID (Optional)
Value Description
FF Unordered List
01 End of List
06 Length of this Entry
Resource Type
00 Resource Size equals 0. The queried Resource Type, ID
Format, or ID is unknown, unsupported, or inconsistent.
01 Deletable Single Byte Coded Font
04 Deletable Overlays
05 Resource Size equals 0
FF The List Query requested is not supported.
01 Resource ID Format (RIDF)
Host-Assigned Resource ID
Resource Size Indicator
00 Resource Not Present
01 Resource Present
XXXX Resource ID
Value Description
F600 EHC Order Code
Data
