Selection Buttons

Trim Buttons

Grip Buttons

Connection Ports

Display s next reading.
OK
Sets the currently edited v alue to its maximum
v alue.
Sets the currently edited v alue to its minimum
v alue.
Cancels any changes made and resets v alue to
where it was before you started editing.
Resets the v alue to the factory default
Left steering trim
button
Right steering trim
button
Performs shifting action on channel 3.
Headphone
port
Computer port
In the function menu
T1 A djusts the throttle dual rate setting.
T2 A djusts the steering dual rate setting.
T3 A djusts the throttle trim setting.
A djusts the steering trim to the left or
right
A djusts the steering trim to the left or
right.
A ccepts a 1/8" stereo headphone jack . The
output is the same in each ear (mono).
This connects to the USB port of y our
computer using the supplied cable.
4
• Increases selected v alue.
• Goes to next sub-menu.
• Goes to selected sub-menu
• Sav es the change to the
selected setting.
