Converting For Left Handed Use - Nomadio Sensor User Manual

Converting for Left Handed Use

You can easily convert the Sensor to left-handed use.
7/64" hex wrench
A: Remove the Steering Wheel Assembly
B: Remove the Speaker Assembly
C: Swap the Assemblies
Tools needed:
A1: Make sure the Sensor is turned off
A2. Carefully remove the Nomadio emblem in the
center of the steering wheel. It is held in place by
friction and pulls toward you, it does not twist.
A3. Use the Phillips screwdriver to loosen and remove
the screw holding the steering wheel. Remove the
steering wheel.
A4. Use the hex wrench to remove the three screws
holding the steering wheel assembly.
A5. Carefully pull the steering wheel assembly away
from the Sensor body.
A6. Carefully unplug the connector from the steering
wheel assembly.
B1. Use the hex wrench to remove the four screws
holding the speaker assembly.
B2. Pull the speaker assembly away from the Sensor
body.
B3. Use the Phillips screwdriver to remove the two
speaker clamp screws holding the speaker to the plastic
cover.
C1. Pass the steering wheel connector wire through the
Sensor body so it comes out the LEFT side hole (where
the speaker used to be).
C2. Pass the speaker through the Sensor body so it
comes out the RIGHT side hole (where the steering
wheel used to be).
7
#2 Phillips screwdriver,
