Throttle Functions

The following illustration shows the function menu structure for the throttle functions:
Throttle Trim
Throttle ( Ch 2 )
Throttle trim adjusts the resting
(centered) position of the throttle
servo horn (electric or nitro
vehicle) or the neutral point of an
ESC (electric vehicle).
When initially setting up the
vehicle, the throttle trim setting
should be set to 0. On a throttle
servo, the servo horn should be
positioned as appropriate on the
servo.
30
Trim - 100 to 100
Dual Rate 0 - 100
Throttle Expo - 100 to 100
Brake Expo - 100 to 100
Sub Trim - 100 to 100
Trim Increment 1 - 20
DR Increment 1 - 20
Brake End Point 0 to 100
Throttle End Point 0 to 100
Servo Reverse Off , On
Servo Type Analog , Digital
Servo Speed Thr/Brake Speed,Trigger ,
