Nomadio Sensor User Manual page 21

Adjusting Steering Trim using the Function Menu
Use the navigation controls to adjust steering trim as follows:
1. A ccess the top function menu
from the driv ing screen.
2. Nav igate to the Steering (Ch1)
menu.
3. Nav igate to Trim.
4. Change the v alue.
Adjusting Steering Trim using the Steering Trim Buttons
You can use the steering trim buttons on the left and right sides of the Sensor to adjust steering trim. Push the
trim button forward to adv ance the trim, backward to reduce it. If y ou hav e a sound attached to the trim
adjustment y ou will hear the sound each time the trim is changed.
A trim (or sub-trim) setting of 100 is equivalent to an End Point setting of 20.
m enu
or : then
or
Value
0
-v e v alue
or
(-100
1)
+v e v alue
(1 100)
18
Description
Steering trim is centered within the serv o
range.
Steering trim is to the LEFT.
-
Steering trim is to the RIGHT.
