Nomadio Sensor User Manual page 45

The position of the pointer on the bar is affected by end point values (throttle and
brake) and trim setting; increasing the throttle end point value may visually appear to
have the same effect as decreasing the brake end point value.
Adjusting the Throttle End Point
The throttle end point value is a relative value, and is expressed as the percentage of full
travel to the THROTTLE end. For example, setting the throttle end point value to "50" allows
the throttle to go to only 50% of full travel to the throttle end.
Use the navigation controls to adjust the throttle end point as follows:
1. A ccess the top function menu from
the driv ing screen.
2. Nav igate to the Throttle (Ch2)
menu.
3. Nav igate to Throttle End Point.
4. Change the v alue.
Trim and EPA Interaction
A trim (or sub-trim) setting of 100 is equiv alent to an End Point setting of 20.
Throttle Servo Reverse
menu
or : then
or
Value Description
0 Minimum throttle end point; allows NO throttle.
Throttle end point v alue is set to a percentage
or of full throttle trav el.
1-99
For example, a v alue of "50" giv es 50% full
throttle trav el.
Maximum throttle end point; allows FULL
100
throttle trav el.
Throttle servo reversing
reverses the direction the
throttle servo moves upon
receiving an input from the
throttle trigger.
42
