Changing the brake end point value has the following visual effect on the driving screen bars.
The position of the pointer on the bar is affected by end point settings (throttle and
brake) and trim setting; increasing the brake end point value may visually appear to
have the same effect as decreasing the throttle end point value.
Brake End Point
Brak e end point v alue is approximately the same as the throttle end
point v alue.
Increased brak e end point v alue (more serv o trav el for BRA KING is
possible).
Decreased brak e end point v alue (less serv o trav el for BRA KING is
possible).
39
On the driv ing screen,
the brak e end point is
represented by the
length of the bar to
the left of the pointer
on the middle bar.
The greater the left
length of the bar, the
Steering (Ch1)
greater the brak e end
point v alue.
Throttle (Ch2)
Shift (Ch3)
The position of the
pointer on the bar
is affected by end
point settings
(throttle and
brake) and trim
setting.
