Nomadio Sensor User Manual page 50

Adjusting Shift Servo Trim
Use the navigation controls to adjust shift servo trim as follows:
1. A ccess the top function menu
from the driv ing screen.
2. Nav igate to the Shift (Ch3)
menu.
3. Nav igate to Trim.
4. Change the v alue.
Trim and EPA Interaction
A trim (or sub-trim) setting of 100 is equivalent to an End Point setting of 20.
Shift Servo Dual Rate
menu
or : then
or
Value
or -v e v alue
(-100
+v e v alue
(1
Shift servo dual rate adjusts the
range of servo movement when
the grip buttons are activated.
The shift servo dual rate value is
applied to both low and high
ends, and is expressed as a
percentage of servo range
(configured by end point
adjustments).
Dual Rate Range
47
Description
0 Shift serv o trim is centered within the
serv o range.
Shift serv o trim is to the LOW end.
-1)
Shift serv o trim is to the HIGH end.
100)
Steering (Ch1)
Throttle (Ch2)
Shift (Ch3)
On the driv ing screen,
shift serv o dual rate
range is represented by
the solid length of the
bottom bar.
The total length of the
bar (solid and dotted)
represents the serv o
range. The length of the
solid bar represents the
serv o range as set by
the dual rate v alue.
