Nomadio Sensor User Manual page 56

Changing the Shift Servo Type
Use the navigation controls to change the shift servo type as follows:
1. A ccess the top function menu
from the driv ing screen.
2. Nav igate to the Shift (Ch3)
menu.
3. Nav igate to Servo Type.
4. Change the v alue.
Shift Servo Mode
Changing the Shift Servo Mode
Use the navigation controls to change the shift servo mode as follows:
1. A ccess the top function
menu from the driv ing screen.
2. Nav igate to the Shift (Ch3)
menu.
3. Nav igate to Mode.
4. Change the v alue.
menu
or : then
or
Value
or
A nalog
Digital
Shift servo mode controls the operation of the shift
function.
menu
or : then
or
Value
Off
Toggle
or
Hold
4WS
Thr/Brak e
53
Description
Shift serv o is analog.
Shift serv o is digital.
Description
No action; shift serv o stay s at trim position.
Shift serv o starts at Low. Pressing the grip button
mov es the shift serv o to High. Releasing and
pressing the grip button again mov es the shift serv o
back to Low.
Serv o starts at Low. Holding the grip button mov es
the shift serv o to High. Releasing the grip button
mov es the serv o back to Low.
4-wheel steering mode. Shift serv o output is
controlled by the steering wheel, just lik e the
steering serv o.
Throttle/Brak e mode. Shift servo output is controlled
by the trigger, just lik e the Throttle serv o
