Changing the left end point value has the following visual effect on the driving screen bars.
The position of the pointer on the bar is affected by the steering end point settings (left
and right) and trim setting; increasing the left end point value may visually appear to
have the same effect as decreasing the right end point value.
Adjusting the Left End Point
The left end point value is a relative value, and is expressed as the percentage of full travel to
the left. For example, setting the left end point value to "50" allows the steering servo to turn
only 50% of full travel to the left.
Use the navigation controls to adjust the left end point as follows:
1. A ccess the top function menu from
the driv ing screen.
2. Nav igate to the Steering (Ch1)
menu.
3. Nav igate to Left End Point.
4. Change the v alue.
Trim and EPA Interaction
A trim (or sub-trim) setting of 100 is equiv alent to an End Point setting of 20.
Left end point v alue is approximately the same as the right end point
v alue.
Increased left end point v alue (more servo trav el to the left is possible).
Decreased left end point v alue (less serv o trav el to the left is possible).
menu
or : then
or
Value
0
or
1-99
100
25
Description
Minimum left end point; allows NO turning
motion to the left.
Left end point v alue is set to a percentage of
full left-turning range. For example, a v alue of
"50" giv es 50% of full left-turning range.
Maximum left end point; allows FULL left-
turning range.
