Security Guide for ProCurve 9300/9400 Series Routing Switches
ProCurveRS(config-if-e100-2/1)# ip verify unicast external-interface
When an interface is identified as an external interface with this command, it prevents the HP device from creating
RPF CAM entries for routes learned on the interface. Unicast RPF is not performed for incoming packets on the
interface.
Syntax: [no] ip verify unicast external-interface
Specifying a Prefix List for Unicast RPF
When unicast RPF is enabled on an external interface, the HP device compiles a list of the internally learned
routes in the device's routing table and creates unicast RPF CAM entries that deny packets with source IP
addresses corresponding to these routes.
In addition, you can create an IP prefix list containing a list of routes and then specify the IP prefix list as part of the
unicast RPF configuration. When you do this, the HP device creates unicast RPF CAM entries that deny packets
with source IP addresses corresponding to the routes in the IP prefix list, in addition to the internally learned
routes. Using an IP prefix list in this way allows you to configure the device to deny packets from networks other
than internal ones.
For example, the following commands create an IP prefix list called "martians" consisting of three routes:
ProCurveRS(config)# ip prefix-list martians seq 5 deny 0.0.0.0/8 le 32
ProCurveRS(config)# ip prefix-list martians seq 10 deny 10.0.0.0/8 le 32
ProCurveRS(config)# ip prefix-list martians seq 15 deny 127.0.0.0/8 le 32
NOTE: For information on creating IP prefix lists, see the Advanced Configuration and Management Guide for
ProCurve 9300/9400 Series Routing Switches.
The following commands specify the "martians" IP prefix list as part of the unicast RPF configuration for interface
e 1/1:
ProCurveRS# interface e 1/1
ProCurveRS(config-if-1/1)# ip verify unicast reverse-path external prefix-list
martians
Syntax: [no] ip verify unicast reverse-path external prefix-list <name>
This command causes the device to drop packets incoming on interface e 1/1 that have source addresses
corresponding to the routes in the "martians" prefix list (as well as packets with source addresses corresponding
to internally learned routes, as well as the device's loopback address/network).
Displaying Unicast RPF Information
To display information about the CAM entries created for unicast RPF, enter the following command:
ProCurveRS# show ip rpf
Total number of RPF route entries 4
Destination
40.0.0.0
30.0.0.0
192.168.135.0
65.0.0.0
Syntax: show ip rpf [<ipaddr> | <ipaddr>/<mask-length> | <portnum> | <ve>]
9 - 4
NetMask Port
255.255.255.0 3/9
255.255.255.0 3/9
255.255.255.0 v2
255.255.255.252 3/9
VLAN ID Deny
1 32778
1 32779
2 32769
1 32770
