Application Guide
PVED-CLS startup guide
Parameter setting
P3097 input voltage scaling
Input voltage
12V coil
12V
100%
24V
50%
36V
33%
8 |
©
Danfoss | October 2018
PVED-CLS parameter acceptance
Use the following steps to save and approve the parameters that have been set.
1. Press Download and wait for the script to complete.
2. Click Close.
It is mandatory to confirm that the parameters have been downloaded by the user.
3. Press Approve Parameters.
The text will change to Approved and the page can then be closed.
Leaving the page before parameters are accepted will cause an EEPROM fault and the PVED-CLS will
go to safe-state mode.
24V coil
N/A
100%
67%
AB285975085591en-000101
