Application Guide
PVED-CLS startup guide
Parameter setting
PVED-CLS SEHS protocol data P3311-P3333
©
Danfoss | October 2018
Example parameter settings
If the parameter change is not described below or conditions are not met, use the default values.
Parameter
Condition for value change
P3311-P3317
Leave at default unless PGN's conflict with others on the CAN bus or another addressing
scheme is desired
P3328
Leave at default unless PGN's conflict with others on the CAN bus or another addressing
scheme is desired
P3332
Leave at default unless PGN's conflict with others on the CAN bus or another addressing
scheme is desired
P3329
Leave at default unless PGN's conflict with others on the CAN bus or another addressing
scheme is desired
P3318-P3323
Leave at default unless PGN's conflict with others on the CAN bus or another addressing
scheme is desired
P3324
Leave at default unless "Proprietary B" message formatting of MMI is desired. If "Proprietary
B" is chosen, PGN offsets can be edited via P3325.
Approve the parameters by following the steps in
PVED-CLS parameter acceptance
AB285975085591en-000101 | 15
on page 8.
