How To Use This Manual; Software Level - rotork Pakscan IIE System Manual

How to use this Manual

In order to make the best use of the information in the following pages we suggest you use this
manual as follows:
Familiarise yourself with the hardware - section 4 will show you all the parts
Read sections 4 to 12 before attempting to commission the system
Refer to section 6 to check the internal link settings
Section 8 relates to the front panel LED's, keypad and LCD screen
Make sure you understand how to connect the system - section 7 tells you how
Set up the Software selected parameters - also see section 9
With a Hot Standby system check the information in section 10
Commissioning the system is explained in section 13
If you have RS485 Converter units, read section 11 carefully
Ethernet connections are explained in section 12
Record the information about your system on data sheets such as those outlined in section
15, or use Rotork MasterTools to document the system. Pakscan Ethernet systems can
also record the master station data to file from the web server application.

Software level

This technical manual relates to Pakscan IIE master stations with software version 5206-014 V5.8 or
later for the main V25 processor and version 5206-034 V5.2 or later for the loop processor.
MasterTools
The software utility, MasterTools, runs on a PC and maybe downloaded from www.rotork.com.
With this utility a complete record of the Pakscan loop, the field units and master station settings
can be made and retained either as an electronic file or the data may be printed out.
