15 SET UP DATA RECORDS

A copy of the following table should be completed for every master station in the system. Keep the
record safe so that in the unlikely event of a failure settings can quickly be restored when replacing a
unit.
Master Station Setup Record:
Master Station Modbus Address
Master Station IP Address
Protocol
Protocol
Alarms
Security
Loop
ESD
Tag Names
Clock
Software version
Ethernet
Ethernet
Ethernet
117 of 132
Ethern
Selected on Port 1
Baud Rate
Selected on Port 2
Baud Rate
Access Level
Baud Rate
Highest FCU address
Doubling
Retain data on comms loss
IQ DV Convert
Serial Input
Keypad
Input terminal
Admin User Name
Admin Password
Netmask
E-mails
Serial Number
Supply Voltage
