14 MASTER STATION SOFTWARE VERSION

The software version and type of the master station is displayed on the Top Diagnostic Display (8.7.1).
A record should be made of this data, together with the serial number of the system, for future
reference.
The serial number will be found on a data label on the rear of the unit.
The master station type includes a code as follows:
01 = Pakscan IIE system
1 = Single Unit
2 = Hot Standby unit
1 = 60 channels maximum
2 = 120 channels maximum
3 = 180 channels maximum
4 = 240 channels maximum
The version code is V: X.X, where digits following the V are the version number.
Both the V25 CPU and the Loop Driver cards have their own software. The version of software for
these two processors must be compatible.
115 of 132
S/W Type : X X X X
