Pakscan IIE System Manual

8.7 Diagnostic Menus

8.7.1

Top Diagnostic Display

Software version
Port 1 activity
Port 2 activity
Loop diagnostics
The top line shows the code for the software type fitted and its version numbers:
011X -
012X -
01X1 -
01X2 -
01X3 -
01X4 -
V5.8/V5.2 -
The port activity flags flash to indicate when a message is received (Rx), or when a reply is transmitted
(Tx).
The centre of the fourth line contains a number that indicates loop activity and the field unit that is
currently passing data to the master station (0 or 255 may be shown when no data is being passed),
The message 'x2' indicates when the loop is running at double speed. Inter-unit communications
applies to hot standby systems only and is information about the data exchange between the two units
in the hot standby pair.
Commands available:
1
-
-
2
-
3
4 -
-
MENU
42 of 132
S/W:0124 V5. 8/V5. 2
1>Port 1
2>Port 2
3>Loop
single master station
hot standby master station
60 channel unit
120 channel unit
180 channel unit
240 channel unit
(X means doesn't matter)
V25 card software version, (5206-014) and loop driver software version,
(5206-034)
Go to Port 1 diagnostic page
Go to Port 2 diagnostic page
Go to Loop diagnostic page
Go to Inter-unit comms page (hot standby systems only)
Return to previous menu
Publication S177E V2.0 Issue 03/05
Rx Tx
Rx Tx
1 x2 >4
Inter-unit comms
