Pakscan IIE System Manual

8.9 Field Unit Menus

The master station displays a screen appropriate to the type of field unit.
8.9.1

Actuator Field Unit Status Display

Digital status
Digital status
Measured value (position)
FCU commands
Digital Status key:
(The display shows a '0' if the state is false and a '1' if it is true)
OA - Open Limit Switch
MO - Running Open
MR - Motor Running
LB
- appears if field unit is in loopback
Alarms key:
(The letter is present if the alarm has occurred)
F - FCU memory failure
P - Power on reset
C - Communications failure
W - Watchdog reset
r - Monitor relay
l - Local stop pressed
c - Control Not Available
t - Thermostat tripped
Commands available:
1
-
2 -
-
3
-
4
5
-
-
9
-
MENU
Note: When the Access Level is set to 3 or 4, to issue a command the correct PIN must be
entered first. Pressing command keys 1, 2, 3, or 4 causes a confirmation screen to
appear before the command is sent.
62 of 132
OA1 ST0 MO0 FCUTAG01
CA0 MR0 MC0
MV=100% 9>Alms=P
1>O 2>C 3>S 4>DV
Send Open command
Send Close command
Send Stop command
Send Set DV command. The master station prompts for the new DV before
sending the command
Go to secondary data page
Go to alarm detail page (full text details of field unit alarms)
Return to previous menu
Publication S177E V2.0 Issue 03/05
Tag name
1
FCU address
Alarm status
5>
More options
CA - Close Limit Switch
MC - Running Closed
ST - Stopped in mid-travel
j - Valve jammed
o - Valve obstructed
e - Motor running at end of travel
m - Manual operation
s - Start/Stop failure
a - Auxiliary override alarm (IQ only)
x - Travel time exceeded (IQ only)
CLEAR
The Up and Down arrow
keys are used to scroll
through the field units
CLEAR - Accept alarms
