Second Page For General Purpose Field Unit - rotork Pakscan IIE System Manual

8.9.3.1

Second Page for General Purpose Field Unit

Pulse counter
Relay commands
Analogue output
Digital input 1 on a GPFCU can be used as a pulse counter. The master station screen will count
pulses up to 9999 before rolling over to 0 and starting again.
Options 1 to 4 prompt the user to Energise (1) or De-energise (0) the relay before the command is
sent.
Note: The general Purpose Field Unit may be configured for fleeting relay outputs, in which
case it will not action the de-energise commands, and if the relays are energised their
status will always display 0.
Option 5 prompts the user to enter a data value for the analogue output in the range 0 to 100 %.
Commands available:
-
-
-
1
2 -
3
-
-
4
5 -
6 -
-
MENU
Note: When the Access Level is set to 3 or 4, to issue a command the correct PIN must be
entered first. Pressing command keys 1, 2, 3, or 4 causes a confirmation screen to
appear before the command is sent.
67 of 132
Pulses=
1>R1=0
3>R3=0
5>Aout=
Go to next field unit
Go to previous field unit
Operate relay 1
Operate relay 2
Operate relay 3
Operate relay 4
Set analogue output
Go to secondary data page
Return to previous menu
Publication S177E V2.0 Issue 12/04
44 FCUTAG01
Tag name
2>R2=0 1
FCU address
4>R4=0
0% 6>
Block and parameter screen
Interface and Menus
