Flowpak Actuator Field Unit Status Display - rotork Pakscan IIE System Manual

8.9.2

Flowpak Actuator Field Unit Status Display

Digital status
Digital status
Measured value (position)
FCU commands
Digital Status key:
(The display shows a '0' if the state is false and a '1' if it is true)
OS - Open Limit Switch
TO - Travelling Open
TR - Valve Travelling
LB - appears if field unit is in loopback
Alarms key:
(The letter is present if the alarm has occurred)
F - FCU memory failure
P - Power on reset
C - Communications failure
W - Watchdog reset
s - Start/Stop failure
m
- Manual operation
Commands available:
1
-
2
-
-
3
-
4
5
-
-
9
-
MENU
Note: When the Access Level is set to 3 or 4, to issue a command the correct PIN must be
entered first. Pressing command keys 1, 2, 3, or 4 causes a confirmation screen to
appear before the command is sent.
65 of 132
OS1 ST0 TO0 FCUTAG01
CS0 TR0 TC0
MV=100% 9>Alms=P
1>O 2>C 3>S 4>DV
Send Open command
Send Close command
Send Stop command
Send Set DV command.
The master station prompts for the new DV before sending the command
Go to secondary data page
Go to alarm detail page (full text details of field unit alarms)
Return to previous menu
Publication S177E V2.0 Issue 12/04
Tag name
1
FCU address
Alarm status
5>
More options
ST - Stopped in mid-travel
CS - Close Limit Switch
TC - Travelling Closed
j - Valve jammed
o - Valve obstructed
l - Local stop pressed
r - Monitor relay
t - Low pressure
c
- Control Not Available
CLEAR
Interface and Menus
The Up and Down arrow
keys are used to scroll
through the field units
CLEAR - Accept alarms
