8.8 Setup Menus

Note: The Setup options can be PIN protected. See sections 8.3 and 8.8.9
8.8.1

Top Setup Menu

Port setup
Loop options
Set tag names
ESD options
Note: When the Ethernet connections are being used the port settings are critical. See
section 12.
Commands available:
1
-
-
2
3 -
-
4
5 -
-
6
-
7
8 -
-
MENU
51 of 132
1>Ports
3>Loop
5>Tags
7>ESD
Go to Port 1 setup page
Go to Standby mode menu page
Go to Loop options page
Change unit address used in communications with host computers,
Go to FCU Tag names page
Go to Date and Time setup page
Go to ESD configuration page
Go to Access level and security page
Return to previous menu
Publication S177E V2.0 Issue 12/04
2>Standby
Only shows on hot standby units
4>Address
Unit addresses
6>Time
Date and time
8>Security
Access level settings
Interface and Menus
