IQ Actuator Second Status Page

Current torque
Auxiliary inputs
This screen only appears for IQ and similar actuators, it shows the current torque value and the status
of the 4 auxiliary digital inputs on an IQ actuator. The flag "LoBat" is displayed if the field unit is
reporting that the battery within the actuator is low.
Commands available:
-
-
1 -
-
2
-
MENU
63 of 132
Torq=85%
Aux1=1 Aux2=0
Aux3=0 Aux4=0
1>Torque
Go to next field unit
Go to previous field unit
Go to torque display screen
Go to secondary data page
Return to previous menu
Publication S177E V2.0 Issue 12/04
FCUTAG01
Tag name
1
FCU address
LoBat
Battery status
2>
More options
