S/E LED
Power OFF or state
NMT_GS
NMT_GS_INITIALISATION
NMT_CS_NOT_ACTIVE
NMT_MS_NOT_ACTIVE
Device Operational
Flickering
NMT_CS_BASIC_ETHERNET
Blinking
NMT_CS_Stopped
Single flash
NMT_CS_PRE_OPERATIONAL_1
NMT_MS_PRE_OPERATIONAL_1
Double flash
NMT_CS_PRE_OPERATIONAL_2
NMT_MS_PRE_OPERATIONAL_2
Triple flash
NMT_CS_READY_TO_OPERATE
NMT_MS_READY_TO_OPERATE
Table 2.3 Behaviour of S/E Leds
L/C LED
Power OFF or NO Link
Link
Table 2.4 Behaviour of L/C LEDs
