Appendix A: Web-based User Options

Introduction

When a computer is connected to the one-X Quick Edition network, you can use the web
browser on the computer to access and manage some telephone and user options through the
web-based User Options interface. For best results, choose Microsoft Internet Explorer 6.0 (or
later) or Mozilla Foxfire 1.0 (or later).
Note:
Refer to the Avaya one-X Quick Edition Telephone User Guide for feature details.
Note:
Refer to
a list of Web-based and telephone interface-configurable options.

Logging On

To log on to the web-based User Options interface, you need to know the IP address,
extension number, and the user options password for the telephone. To display the IP address
of the telephone, press # and PAGE LEFT or PAGE RIGHT (
To access telephone and user options using a web browser
1. Start the web browser on your computer.
2. In the Address field, enter the IP address of the telephone (for example, https://
192.168.0.2).
If you have not disabled the first security alert, a Security Alert message is displayed.
3. Click OK. If you have not installed the self-signed security certificate on your computer, a
Security Alert action request is displayed.
4. To proceed without installing the security certificate, click Yes, or to install the security
certificate, click View Certificate. When the Certificate dialog box is displayed, click Install
Certificate and follow the on-screen instructions.
5. On the Login dialog box, enter the telephone extension number and password.
6. Click Login.
The User Options Home page for the telephone is displayed.
Avaya one-X Quick Edition Release 3.1.0 System Administration Guide
Appendix B: Menus, Call Detail Recording, Specifications on page 95 for
) button.
May 2007
91
