Evaluation Board User Guide
Item Qty Reference Designator
1
103 R401, R402, R501, R502, R601
1
104 R406, R506, R719, R720
1
105 R412
106 1 R416
1
107 R417, R418, R419, R420, R421
1
108 R512, R513
109 1 R613
1
110 T403, T503
111 1 T404
1
112 T505, T602
1
113 TP101, TP102, TP402, TP601,
TP801, TP802
114 1
TP9, TP401, TP701, TP702,
TP703, TP704, TP705
1
115 U702
1
116 CR201
1
117 U202
1
Do not install.
Description Value
Res prec, thick 57.6 Ω
film, chip, R0603
Res prec, thick 49.9 Ω
film, chip, R0402
Res prec, thick 130 Ω
film, chip, R0402
Res film, SMD, 0402 300 Ω
Res prec, thick 10 kΩ
film, chip, R0402
Res prec, thick 40.2 Ω
film, chip, R0402
Res film, SMD, 0402 100 Ω
XFMR RF ADT1-1WT
XFMR RF TC3-1T+
XFMR RF 1:1 MABA-007159-000000
(6-pin special)
Connector-PCB, BLK
TST PNT black
WHT
Connector-PCB,
TST PNT white
IC-ADI ultrafast, SIGe ECL ADCLK905BCPZ-WP
clock/data buffers
IC-ADI 1.2 V micropower AD1580ARTZ
precision shunt voltage
reference
IC-ADI single-supply, AD822BRZ
rail-to-rail, low power
FET, input op amp
Rev. A | Page 39 of 40
UG-003
Manufacturer/Part No.
Panasonic/ERJ-3EKF57R6V
Panasonic/ERJ-2RKF49R9X
Panasonic/ERJ-2RKF1300X
Panasonic/ERJ-2GEJ301X
Panasonic/ERJ-2RKF1002X
Panasonic/ERJ-2RKF40R2X
Panasonic/ERJ-2GEJ101X
Mini-Circuits/ADT1-1WT
Mini-Circuits/TC3-1T+
M/A-Com/
MABA-007159-000000
Components Corp./
TP-104-01-00
Components Corp./
TP-104-01-09
Analog Devices, Inc./
ADCLK905BCPZ-WP
Analog Devices, Inc./
AD1580ARTZ
Analog Devices, Inc./
AD822BRZ
