Evaluation Board User Guide
Reference
Item Qty Designator
55 68 C116, C118, C120,
C122, C149, C150,
C151, C152, C153,
C154, C204, C206,
C207, C208, C209,
C211, C301, C302,
C401, C404, C405,
C406, C407, C417,
C418, C420, C426,
C503, C505, C506,
C507, C515, C516,
C523, R524, C601,
C602, C603, C606,
C607, C609, C701,
C702, C710, C711,
C712, C713, C714,
C715, C716, C717,
C718, C719, C720,
C721, C723, C724,
C730, C731, C801,
C802, C803, C804,
C805, C806, C807,
C808, C809
1
55A 0 C403, C504
56 6 C138, C139, C141,
C142, C147, C148
57 3 C107, C203, C205
58A 21 C402, C502, JP403,
R203, R301, R302,
R303, R304, R606,
R609, R610, R611,
R612, R708, R715,
R723, R727, R728,
R729, R803, R804
58B 4 R424, R425, R525, R526
59 1 C604
60 1 C705
61 1 C706
62 1 C707
63 1 C722
64 5 CR101, CR102, CR104,
CR105, CR106
65 1 CR103
66 1 CR601
67 3 CR701, CR801, CR802
68 12
E101, E102, E103,
E105, E107, E109,
E110, E111, E112,
E113, E114, E115
69 1 F101
70 1 FL101
71 1 J201
Description
Capacitor, ceramic, X7R, 0402
Capacitor, ceramic, X7R, 0402
Capacitor, ceramic, X5R, 0805
Capacitor, ceramic, Y5V, 0402
Resistor, 0402, SMD
Resistor, 0402, SMD
Capacitor, ceramic, 0402, SMD
Capacitor, ceramic, 0402, SMD
Capacitor, ceramic, X5R, 0402
Capacitor, ceramic, X7R, 0402
Capacitor, ceramic, X5R, 0402
Rectifier SIL
Surface-mount chip LED, 0603
Schottky diode
LED, thin, diff., 0805, SMD
Bead core, 0805, SMD
Polyswitch, 1812, reset fuse,
SMD
Filter EMI
Square post header
Rev. A | Page 29 of 40
Value
0.1 μF, 16 V
0.1 μF, 16 V
22 μF, 6.3 V, 20%
1 μF, 6.3 V
0 Ω, 1/10 W, 5%
15.0 Ω, 1/16 W, 1%
1000 pF, 25 V
1800 pF, 25 V
0.033 μF, 10%, 16 V
1500 pF, 50 V
0.22 μF, 6.3 V
2 A, 50 V, DO-214AA
Green
20 V , 1.2 pF, SOT-23
BR
635 nm, red
4 A, 100 MHz
1.6 A
50 mΩ, 15 A
025" (0.64 mm), 0.100"
(2.54 mm) centerline
UG-003
Manufacturer/Part No.
Murata/81-GRM155R71C104KA88,
Panasonic/ECJ-0EX1C104K
Murata/81-GRM155R71C104KA88,
Panasonic/ECJ-0EX1C104K
Murata/GRM21BR60J226ME39L
Panasonic/ECJ-0EF0J105Z
Yageo/RC0402JR-070RL,
Panasonic/ERJ-2GE0R00X
Panasonic/ERJ-2RKF15R0X
Panasonic/ECJ-0EB1E102K
Panasonic/ECJ-0EB1E182K
Murata/GRM155R61C333KA01D,
AVX Corp./0402YD333KAT2A
Panasonic/ECJ-0EB1H152K
Panasonic/ECJ-0EB0J224K
Micro Commercial Components
Corp./S2A-TP
Panasonic/LNJ308G8TRA
Avago Technologies/HSMS-2812BLK
Lumex/SML-LXT0805IW-TR
Panasonic/EXC-ML20A390U
Tyco Electronics/MINISMDC160F-2
Murata/BNX016-01
Samtec/TSW-103-08-G-D
