UG-003
Reference
Item Qty Designator
72 4 J203, J402, J501, J602
73 1 J205
74 2 J301, J701
75 1 J302
76 3 J403, J503, J605
77 1 J404
78 2 JP101, JP103
79 3 JP503, L402, L501
80 4 L403, L404, L503, L504
81 1 P101
82 2 P102, P103
83 3 P901, P902, P903
84 1 R101
85 1 R102
86 1 R103
87 1 R104
88 2 R112, R114
89 2 R113, R115
90 8
R206, R208, R209,
R309, R316, R317,
R801, R802
91 2 R207, R733
92 13 R121, R123, R310,
R311, R312, R422,
R522, R614, R704,
R705, R706, R707,
R709
93 5 R105, R106, R313,
R314, R315
94 5 R403, R404, R503,
R504, R741
95 4 R408, R409, R508,
R509
96 1 R602
97 1 R710
98 1 R711
99 8 R714, R716, R725,
R730, R738, R739,
R805, R806
100 2 R726, R740
101 2 R734, R736
102 2 R735, R737
Description
CONN-PCB
CONN-PCB header
CONN-PCB header
CONN-PCB header
CONN-PCB header
CONN-PCB header
Resistor, 0805, SMD
Resistor, 0603, SMD
Resistor, 0603, SMD
CONN power jack
CONN-PCB header
CONN_PCB RA connector
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0603, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor, 0402, SMD
Resistor , 0402, SMD
Rev. A | Page 30 of 40
Evaluation Board User Guide
Value
SMA, ST edge mount
4P double row
8-pin double row
ST male, 9-pin
2 position, single row
ST 10P
0.0 Ω, 1/8 W, 5%
0 Ω, 1/10 W, 5%
0.0 Ω, 1/10 W
2.1 mm × 5.5 mm, HI CUR
6 position
60 pin
300 Ω, 1/16 W, 1%
147 kΩ, 1/10 W, 1%
28.0 kΩ, 1/10 W, 1%
10.0 Ω, 1/10 W, 1%
18.7 kΩ, 1/10 W, 1%
15.0 kΩ, 1/10 W, 1%
10.0 kΩ, 1/16 W, 1%
57.6 Ω, 1/16 W, 1%
1.00 kΩ, 1/16 W, 1%
100 kΩ, 1/16 W, 1%
33 Ω, 1/10,W, 5%
33 Ω, 1/10,W, 5%
57.6 Ω, 1/10 W, 1%
4.12 kΩ, 1/16 W, 1%
5.11 kΩ, 1/16 W, 1%
200 Ω, 1/10 W, 1%
100 Ω, 1/10 W, 5%
130 Ω, 1/16 W, 1%
82.5 Ω, 1/16 W, 1%
Manufacturer/Part No.
Emerson Network Power
Connectivity Solutions/142-0711-821,
Samtec/SMA-J-P-H-ST-EM1
Samtec/TSW-102-08-G-D
Samtec/TSW-104-08-T-D
Samtec/TSW-103-08-G-T
Samtec/TSW-102-08-G-S
Samtec/TSW-105-08-G-D
Panasonic/ERJ-6GEY0R00V
Rohm Semiconductor/MCR03EZPJ000,
Panasonic/ERJ-3GEY0R00V
Panasonic/ERJ-3GEY0R00V
CUI/PJ-002AH-SMT
Wieland/Z5.531.3625.0
Tyco Electronics/6469169-1
Rohm Semiconductor/
MCR01MZPF3000,
Panasonic/ERJ-2GEJ301X
Panasonic/ERJ-2RKF1473X
Panasonic/ERJ-2RKF2802X
Panasonic/ERJ-2RKF10R0X
Panasonic/ERJ-2RKF1872X
Panasonic/ERJ-2RKF1502X
Yageo/RC0402FR-0710KL,
Panasonic/ERJ-2RKF1002X
Panasonic/ERJ-2RKF57R6X
Yageo/RC0402FR-071KL,
Panasonic/ERJ-2RKF1001X
Rohm Semiconductor/
MCR01MZPF1003,
Panasonic/ERJ-2RKF1003X
Rohm Semiconductor/
MCR01MZPJ330,
Panasonic/ERJ-2GEJ330X
Panasonic/ERJ-2GEJ330X
Panasonic/ERJ-3EKF57R6V
Vishay/CRCW04024K12FKED,
Panasonic/ERJ-2RKF4121X
Vishay/CRCW04025K11FKED,
Panasonic/ERJ-2RKF5111X
Panasonic/ERJ-2RKF2000X
Panasonic/ERJ-2GEJ101X
Vishay/CRCW0402130RFKED,
Panasonic/ERJ-2RKF1300X
Panasonic/ERJ-2RKF82R5X
