UG-003
Item Qty Reference Designator
8 27 C401, C402, C502, JP403, R203, R301, R302,
R303, R304, R424, R425, R524, R525, R526,
R606, R609, R610, R611, R612, R708, R715,
R723, R727, R728, R729, R803, R804
9 1 C604
10 1 C705
11 1 C706
12 1 C707
13 1 C722
14 5 CR101, CR102, CR104, CR105, CR106
15 1 CR103
16 1 CR601
17 3 CR701, CR801, CR802
18 12 E101, E102, E103, E105, E107, E109,
E110, E111, E112, E113, E114, E115
19 1 F101
20 1 FL101
21 1 J201
22 4 J203, J402, J501, J602
23 1 J205
24 2 J301, J701
25 1 J302
26 3 J403, J503, J605
27 1 J404
28 2 JP101, JP103
29 3 JP503, L402, L501
30 4 L403, L404, L503, L504
31 1 P101
32 2 P102, P103
33 3 P901, P902, P903
34 1 R101
35 1 R102
36 1 R103
37 1 R104
38 2 R112, R114
Description
Res film, SMD, 0402
Capacitor, ceramic
Capacitor, ceramic,
multilayer, X7R, 0402
Capacitor, ceramic
Capacitor, ceramic, 0402
Capacitor, ceramic
Diode recovery rectifier
LED green,
surface mount
Diode, Schottky,
dual series
LED red, surface mount
Inductor ferrite bead
Fuse, polyswitch,
PTC device
Filter noise suppression,
LC-combined type
Connector-PCB, Berg,
header, double STR,
male, 6 pos
Connector-PCB,
SMA, ST edge mount
Connector-PCB,
header, 4 pos, ST
Connector-PCB, header,
8 pos, double row
Connector-PCB, header,
ST male, 9 pos
Connector-PCB,
header, 2 pos
Connector-PCB,
header, ST, 10 pos
Res jumper,
SMD, 0805 (SHRT)
Res film, SMD, 0603
Inductor, ferrite bead
Connector-PCB, power
jack, surface mount
Connector-PCB,
header, 6 pos
Connector-PCB,
60-pin, RA connector
Res film, SMD, 0402
Res prec, thick
film, chip, R0402
Res prec, thick
film, chip, R0402
Res prec, thick
film, chip, R0402
Res prec, thick
film, chip, R0402
Rev. A | Page 32 of 40
Evaluation Board User Guide
Value Manufacturer/Part No.
0 Ω Panasonic/ERJ-2GE0R00X
1000 pF Panasonic/ECU-E1E102KBQ
1800 pF Panasonic/ECJ-0EB1E182K
0.033 μF Panasonic/
0402YD333KAT2A
1500 pF Panasonic/ECJ-0EB1H152K
0.22 μF Panasonic/ECJ-0EB0J224K
S2A-TP Micro Commercial
Components Corp./S2A-TP
LNJ308G8TRA Panasonic/LNJ308G8TRA
(green)
HSMS-2812BLK Avago Technologies/
HSMS-2812BLK
SML-LXT0805IW-TR Lumex/SML-LXT0805IW-TR
100 MHz Panasonic/
EXC-ML20A390U
1.6 A Tyco Electronics/
MINISMDC160F-2
BNX016-01 Murata/BNX016-01
TSW-103-08-G-D Samtec/TSW-103-08-G-D
SMA-J-P-X-ST-EM1 Samtec/SMA-J-P-X-ST-EM1
TSW-102-08-G-D Samtec/TSW-102-08-G-D
TSW-104-08-T-D Samtec/TSW-104-08-T-D
TSW-103-08-G-T Samtec/TSW-103-08-G-T
TSW-102-08-G-S Samtec/TSW-102-08-G-S
TSW-105-08-G-D Samtec/TSW-105-08-G-D
0 Ω Panasonic/ERJ-6GEY0R00V
0 Ω Panasonic/ERJ-3GEY0R00V
10 Ω @ 100 MHz Murata/BLM18BA100SN1
PJ-002AH-SMT CUI, Inc./PJ-002AH-SMT
Z5.531.3625.0 Wieland/Z5.531.3625.0
6469169-1 Tyco Electronics/6469169-1
300 Ω Panasonic/ERJ-2GEJ301X
147 kΩ Panasonic/ERJ-2RKF1473X
28 kΩ Panasonic/ERJ-2RKF2802X
10 Ω Panasonic/ERJ-2RKF10R0X
18.7 kΩ Panasonic/ERJ-2RKF1872X
