Evaluation Board User Guide
Item Qty Reference Designator
39 2 R113, R115
40 8 R206, R208, R209, R309, R316, R317,
R801, R802
41 2 R207, R733
42 13 R121, R123, R310, R311, R312, R422, R522,
R614, R704, R705, R706, R707, R709
43 5 R105, R106, R313, R314, R315
44 5 R403, R404, R503, R504, R741
4 R408, R409, R508, R509
46 1 R602
47 1 R710
48 1 R711
49 8 R714, R716, R725, R730, R738, R739,
R805, R806
50 2 R726, R740
51 2 R734, R736
52 2 R735, R737
53 9 RN801, RN802, RN803, RN804, RN805,
RN806, RN807, RN808, RN809
54 5 T401, T402, T501, T502, T602
55 3 U101, U104, U105
56 2 U102, U106
57 1 U103
58 1 U201
59 1 U301
60 3 U302, U703, U803
61 1 U401
62 1 U501
63 1 U701
64 2 U801, U802
65 1 VR101
66 1 Y601-125 for -125 model U201
67 1 Y601-105 for -105 model U201
Description
Res chip, SMD, 0402
Res prec, thick,
film chip, R0402
Res prec, thick,
film chip, R0402
Res prec, thick,
film chip, R0402
Res prec, thick,
film chip, R0402
Res film, SMD, 0402
Res film, SMD 0402
Res prec, thick,
film chip, R0603
Res prec, thick,
film chip, R0402
Res prec, thick,
film chip, R0402
Res prec, thick,
film chip, R0402
Res film, SMD 0402
Res prec, thick,
film chip, R0402
Res prec, thick,
film chip, R0402
Res NTWRK, 8-pin/4 res,
surface mount
XFMR RF 1:1 (6-pin special)
IC-ADI, low dropout,
CMOS line regulator
IC-ADI, low dropout,
CMOS line regulator
IC-ADI, low dropout,
CMOS line regulator
Generic LFCSP64-9X9-
9PAD1_8X1_8 footprint
IC TinyLogic®, UHS
dual buffer
IC TinyLogic,
UHS dual buffer
IC ultralow,
distortion IF VGA
IC 2.6 GHz, ultralow
distortion, RF/IF diff amp
IC-ADI 12-output CLK
generator with integrated
1.6 GHz VCO
IC-TTL, low voltage,
20-bit buffer
IC ADI dual configurable,
synchronous, stepdown ,
dc-to-dc regulator
IC clock OSC ACMOS/
LSTTL compatible
IC clock OSC ACMOS/
LSTTL compatible
Rev. A | Page 33 of 40
Value Manufacturer/Part No.
15 kΩ Panasonic/ERJ-2RKF1502X
10 kΩ Panasonic/ERJ-2RKF1002X
57.6 Ω Panasonic/ERJ-2RKF57R6X
1.00 kΩ Panasonic/ERJ-2RKF1001X
100 kΩ Panasonic/ERJ-2RKF1003X
33 Ω Panasonic/ERJ-2GEJ330X
66.5 Ω Panasonic/ERJ-2RKF66R5X
57.6 Ω Panasonic/ERJ-3EKF57R6V
4.12 kΩ Panasonic/ERJ-2RKF4121X
5.11 kΩ Panasonic/ERJ-2RKF5111X
200 Ω Panasonic/ERJ-2RKF2000X
100 Ω Panasonic/ERJ-2GEJ101X
130 Ω Panasonic/ERJ-2RKF1300X
82.5 Ω Panasonic/ERJ-2RKF82R5X
22 Ω CTS/742C083220JCT
MABA-007159-000000
M/A-Com/
MABA-007159-000000
ADP1708ARDZ-R7 Analog Devices, Inc./
ADP1708ARDZ-R7
ADP1706ARDZ-3.3-R7 Analog Devices, Inc./
ADP1706ARDZ-3.3-R7
ADP1706ARDZ-1.8-R7 Analog Devices, Inc./
ADP1706ARDZ-1.8-R7
AD9268BCPZ-125 or Analog Devices, Inc./
AD9258BCPZ-125 AD9268BCPZ-125 or
AD9258BCPZ-125
NC7WZ07P6X Fairchild Semiconductor/
NC7WZ07P6X
NC7WZ16P6X Fairchild Semiconductor/
NC7WZ16P6X
AD8375ACPZ Analog Devices, Inc./
AD8375ACPZ
ADL5562_PRELIM Analog Devices, Inc./
ADL5562
AD9517-4BCPZ Analog Devices, Inc./
AD9517-4BCPZ
74VCX162827MTDX Fairchild Semiconductor/
74VCX162827MTDX
ADP2114_PRELIM Analog Devices, Inc./
ADP2114
125 MHz Valpey Fisher/
VFAC3BHL-125MHZ
105 MHz Valpey Fisher/
VFAC3BHL-105MHZ
UG-003
