Evaluation Board User Guide
Item Qty Reference Designator
41 13 R121, R123, R310, R311, R312, R422,
R522, R614, R704, R705, R706, R707, R709
42 5 R105, R106, R313, R314, R315
43 9 R403, R404, R408, R409, R503,
R504, R508, R509, R741
44 1 R602
1 R710
46 1 R711
47 8 R714, R716, R725, R730, R738,
R739, R805, R806
48 2 R726, R740
49 2 R734, R736
50 2 R735, R737
51 9 RN801, RN802, RN803, RN804, RN805,
RN806, RN807, RN808, RN809
52 4 T401, T402, T501, T502,
53 1 T601
54 3 U101, U104, U105
55 2 U102, U106
56 1 U103
57 1 U201
58 1 U301
59 3 U302, U703, U803
60 1 U401
61 1 U501
62 1 U701
63 2 U801, U802
64 1 VR101
65 1 Y601-80 for -80 model U201
66 1 Y601-65 for -65 model U201
67 1 Y601-40 for -40 model U201
Description Value
Res prec, thick 1.00 kΩ
film chip, R0402
Res prec, thick 100 kΩ
film chip, R0402
Res film, SMD, 0402 33 Ω
57.6 Ω
Res prec, thick
film chip, R0603
Res prec, thick 4.12 kΩ
film chip, R0402
Res prec, thick 5.11 kΩ
film chip, R0402
Res prec, thick 200 Ω
film chip, R0402
Res film, SMD, 0402 100 Ω
Res prec, thick 130 Ω
film chip, R0402
Res prec, thick 82.5 Ω
film chip, R0402
Res network, 8-pin/4 res, 220 Ω
surface mount
XFMR RF 1:1 MABA-007159-000000
(6-pin special)
XFMR RF ADT1-1WT+
IC-ADI, low dropout, ADP1708ARDZ-R7
CMOS line regulator
IC-ADI, low dropout, ADP1706ARDZ-3.3-R7
CMOS line regulator
IC-ADI, low dropout, ADP1706ARDZ-1.8-R7
CMOS line regulator
Generic LFCSP64-9X9- AD9251BCPZ-xx,
9PAD1_8X1_8 footprint AD9231BCPZ-xx,
AD9204BCPZ-xx,
AD9269BCPZ-xx, or
AD6659BCPZ-xx
IC TinyLogic UHS, NC7WZ07P6X
dual buffer
IC TinyLogic UHS NC7WZ16P6X
dual buffer
IC ultralow, AD8375ACPZ
distortion IF VGA
IC 2.6 GHz, ultralow ADL5562_PRELIM
distortion, RF/IF diff amp
IC-ADI 12-output CLK AD9517-4BCPZ
generator with integrated
1.6 GHz VCO
IC-TTL, low voltage, 74VCX162827MTDX
20-bit buffer
IC ADI dual configurable, ADP2114_PRELIM
synchronous, stepdown ,
dc-to-dc regulator
IC clock OSC, ACMOS/ 80 MHz
LSTTL compatible
IC clock OSC, ACMOS/ 65 MHz
LSTTL compatible
IC clock OSC, ACMOS/ 40 MHz
LSTTL compatible
Rev. A | Page 37 of 40
UG-003
Manufacturer/Part No.
Panasonic/ERJ-2RKF1001X
Panasonic/ERJ-2RKF1003X
Panasonic/ERJ-2GEJ330X
Panasonic/ERJ-3EKF57R6V
Panasonic/ERJ-2RKF4121X
Panasonic/ERJ-2RKF5111X
Panasonic/ERJ-2RKF2000X
Panasonic/ERJ-2GEJ101X
Panasonic/ERJ-2RKF1300X
Panasonic/ERJ-2RKF82R5X
CTS/742C083221JCT
M/A-Com/
MABA-007159-000000
Mini-Circuits/ADT1-1WT+
Analog Devices, Inc./
ADP1708ARDZ-R7
Analog Devices, Inc./
ADP1706ARDZ-3.3-R7
Analog Devices, Inc./
ADP1706ARDZ-1.8-R7
Analog Devices, Inc./
AD9251BCPZ-xx,
AD9231BCPZ-xx,
AD9240BCPZ-xx,
AD9269BCPZ-xx, or
AD6659BCPZ-xx
Fairchild Semiconductor/
NC7WZ07P6X
Fairchild Semiconductor/
NC7WZ16P6X
Analog Devices, Inc./
AD8375ACPZ
Analog Devices, Inc./
ADL5562_PRELIM
Analog Devices, Inc./
AD9517-4BCPZ
Fairchild Semiconductor/
74VCX162827MTDX
Analog Devices, Inc./
ADP2114_PRELIM
Valpey Fisher/
VFAC3BHL-80MHZ
Valpey Fisher/
VFAC3BHL-65MHZ
Valpey Fisher/
VFAC3BHL-40MHZ (
