UG-003
Item Qty Reference Designator
9 2 C410, C510
10 1 C705
11 1 C706
12 1 C707
13 1 C722
14 5 CR101, CR102, CR104, CR105, CR106
15 1 CR103
16 1 CR601
17 3 CR701, CR801, CR802
18 12 E101, E102, E103, E105, E107, E109,
E110, E111, E112, E113, E114, E115
19 1 F101
20 1 FL101
21 1 J201
22 4 J203, J402, J501, J602
23 1 J205
24 2 J301, J701
25 1 J302
26 3 J403, J503, J605
27 1 J404
28 2 JP101, JP103
29 7 JP503, L402, L403, L404, L501, L503, L504
30 1 P101
31 2 P102, P103
32 3 P901, P902, P903
33 1 R101
34 1 R102
35 1 R103
36 1 R104
37 2 R112, R114
38 2 R113, R115
39 8 R206, R208, R209, R309, R316, R317,
R801, R802
40 2 R207, R733
Description Value
Capacitor, ceramic NP0 22 pF
Capacitor, ceramic, 1800 pF
multilayer, X7R, 0402
Capacitor, ceramic 0.033 μF
Capacitor, ceramic, 0402 1500 pF
Capacitor, ceramic 0.22 μF
Diode recovery rectifier S2A-TP
LED green, LNJ308G8TRA (green)
surface mount
Diode, Schottky, HSMS-2812BLK
dual series
LED red, surface mount SML-LXT0805IW-TR
Inductor ferrite bead 100 MHz
Fuse, polyswitch, 1.6 A
PTC device
Filter noise, suppression, BNX016-01
LC-combined type
Connector-PCB, Berg TSW-103-08-G-D
header, double STR,
male 6 pos
Connector-PCB, SMA, SMA-J-P-X-ST-EM1
ST edge mount
Connector-PCB, header, TSW-102-08-G-D
4 pos ST
TSW-104-08-T-D
Connector-PCB, header,
8 pos double row
Connector-PCB, TSW-103-08-G-T
header, ST male, 9 pos
Connector-PCB, TSW-102-08-G-S
header 2 pos
Connector-PCB, TSW-105-08-G-D
header, ST 10 pos
Res jumper, SMD, 0 Ω
0805 (SHRT)
Res film, SMD, 0603 0 Ω
Connector-PCB, power PJ-002AH-SMT
jack, surface mount
Connector-PCB, Z5.531.3625.0
header, 6 pos
Connector-PCB, 6469169-1
60-pin, RA connector
Res film, SMD, 0402 300 Ω
Res prec, thick 147 kΩ
film chip, R0402
Res prec, thick 28 kΩ
film chip, R0402
Res prec, thick 10 Ω
film chip, R0402
18.7 kΩ
Res prec, thick
film chip, R0402
Res chip, SMD, 0402 15 kΩ
Res prec, thick 10 kΩ
film chip, R0402
57.6 Ω
Res prec, thick
film chip, R0402
Rev. A | Page 36 of 40
Evaluation Board User Guide
Manufacturer/Part No.
Panasonic/ECU-E1H220J
Panasonic/ECJ-0EB1E182K
Panasonic/0402YD333KAT2A
Panasonic/ECJ-0EB1H152K
Panasonic/ECJ-0EB0J224K
Micro Commercial
Components Corp./S2A-TP
Panasonic/LNJ308G8TRA
Avago Technologies/
HSMS-2812BLK
Lumex/SML-LXT0805IW-TR
Panasonic/EXC-ML20A390U
Tyco Electronics/
MINISMDC160F-2
Murata/BNX016-01
Samtec/TSW-103-08-G-D
Samtec/SMA-J-P-X-ST-EM1
Samtec/TSW-102-08-G-D
Samtec/TSW-104-08-T-D
Samtec/TSW-103-08-G-T
Samtec/TSW-102-08-G-S
Samtec/TSW-105-08-G-D
Panasonic/ERJ-6GEY0R00V
Panasonic/ERJ-3GEY0R00V
CUI, Inc./PJ-002AH-SMT
Wieland/Z5.531.3625.0
Tyco Electronics/6469169-1
Panasonic/ERJ-2GEJ301X
Panasonic/ERJ-2RKF1473X
Panasonic/ERJ-2RKF2802X
Panasonic/ERJ-2RKF10R0X
Panasonic/ERJ-2RKF1872X
Panasonic/ERJ-2RKF1502X
Panasonic/ERJ-2RKF1002X
Panasonic/ERJ-2RKF57R6X
