UG-003
Item Qty Reference Designator
68 1 Y601-80 for -80 model U201
1
69 C108, C109
1
70 C110
71 1 C111, C113, C519
1
72 C112
1
73 C137, C140
1
74 C408, C409, C410, C411, C508, C509,
C510, C511
1
75 C201, C202, C412, C413, C414, C415,
C416, C421, C427, C512, C513, C521,
C522, C610, C703, C704, C708, C709
1
76 C422, C423
1
77 C424
1
78 C425
1
79 C517, C518
1
80 C520
1
81 E104, E106, E108, E116, E117, E118, E119
1
82 J401, J502, J601, J702, J703, J704
83 1 JP102, JP104
1
84 L101, L102
1
85 L401, L502
1
86 L405, L505
1
87 L406, L407
1
88 L408, L409, L410, L411
1
89 L508, L509
90 1 L510, L520
1
91 L521, L522
1
92 R107
1
93 R108
94 1 R109
1
95 R110, R111
1
96 R116, R117
97 1 R118
1
98 C501, JP401, JP402, JP501, JP502, R120,
R122, R124, R125, R126, R127, R305, R306,
R307, R308, R405, R407, R410, R411, R413,
R414, R415, R423, R505, R507, R510, R511,
R514, R515, R516, R517, R519, R520, R521,
R603, R604, R605, R607, R608, R721, R722,
R731, R732
1
99 R518
1
100 R201
1
101 R202
1
102 R204, R205
Description
IC clock OSC ACMOS/
LSTTL compatible
Capacitor, ceramic,
multilayer, X7R 0402
Capacitor, ceramic
Capacitor, ceramic,
mono cer, C0G, 0402
Capacitor, ceramic, 0402
Capacitor, cer, SMD 0603
Capacitor, ceramic, NP0
Capacitor, ceramic, 0402
Capacitor, ceramic,
multilayer, X7R, 0402
Capacitor, ceramic
Capacitor, mono,
ceramic, C0G, 0402
Capacitor, ceramic
Capacitor, ceramic
Inductor ferrite bead
Connector-PCB
SMA, ST edge mount
Resistor jumper,
SMD, 0805 (SHRT)
Inductor sm
Res film, SMD 0603
Inductor SM
Inductor SM
Inductor SM
Chip inductor
Chip inductor
Inductor SM
Resistor, chip, SMD 0402
Res prec, thick film
chip, R0402
Resistor, chip, SMD 0402
Resistor, chip, SMD 0402
Resistor, chip, SMD 0603
Res film, SMD 0402
Res film, SMD 0402
Res prec, thick
film chip, R0402
Res prec, thick
film chip, R0402
Res VAR 3/8" SQ top adj
Resistor, chip, SMD 0402
Rev. A | Page 34 of 40
Evaluation Board User Guide
Value Manufacturer/Part No.
80 MHz Valpey Fisher/
VFAC3BHL-80MHZ
10,000 pF Panasonic/ECJ-0EB1E103K
2200 pF Phycomp (Yageo)/
CC0402KRX7R9BB222
100 pF
Murata/
GRM1555C1H101JD01D
1500 pF Panasonic/ECJ-0EB1H152K
N/A N/A
5 pF Panasonic/ECJ-E1H050CCQ
0.1 μF Panasonic/ECJ-0EX1C104K
1200 pF Panasonic/ECJ-0EB1E122K
2.7 pF Samsung/CL05C2R7CBNC
20 pF Murata/
GRM1555C1H200JZ01D
1000 pF Panasonic/ECU-E1E102KBQ
39 pF Phycomp (Yageo)/
0402CG390J9B200
100 MHz Panasonic/EXC-ML20A390U
SMA-J-P-X-ST-EM1 Samtec/SMA-J-P-X-ST-EM1
0 Ω Panasonic/ERJ-GEY0R00V
2.2 μH TOKO/FDV0630-2R2M
0 Ω Panasonic/ERJ-3GEY0R00V
100 nH Coilcraft/0603CS-R10XGLU
1 μH Coilcraft/0603LS-102XGLB
270 nH Coilcraft/0603CS-R27XGLW
15 nH Coilcraft/0603CS-15NXGLU
36 nH Coilcraft/0603CS-36NXGLU
82 nH Coilcraft/0603CS-82NXGLU
27 kΩ Panasonic/ERJ-2RKF2702X
10.5 kΩ Panasonic/ERJ-2RKF1052X
4.75 kΩ Panasonic/ERJ-2RKF4751X
15 kΩ Panasonic/ERJ-2RKF1502X
N/A N/A
13 kΩ Yageo Corp./
9C04021A1302FLHF3
0 Ω Panasonic/ERJ-2GE0R00X
1.00 kΩ Panasonic/ERJ-2RKF1001X
2 kΩ Panasonic/ERJ-2RKF2001X
10 kΩ Bourns, Inc./3299W-1-103
N/A N/A
