Chapter 8 : TECHNICAL SPECIFICATIONS (continued)

8-6. AUDIO INPUTS

• 9 Balanced and unbalanced stereo inputs (on 5-pin MCO male connector).
• Vi = + 18 dBu (max).
• Zi = 20 kΩ unbalanced.
• Zi = 40 kΩ balanced.
• Gain = + 6 dB / - ∞ adjustable.

8-7. AUDIO OUTPUTS

• 2 Balanced and unbalanced mono/stereo outputs (on 5-pin MCO male connector).
• Vo max:
Unbalanced = + 18 dBu (+12 dBu with 300Ω load).
Balanced = + 24 dBu (+18 dBu with 600Ω load).
• Zo = 600 Ω balanced.
• Zo = 300 Ω unbalanced.
• G = 0 dB nominal.
• G = + 6 dB / - ∞ adjustable with Master volume.

8-8. ENVIRONMENTAL

Power Supply:
Storage Temperature:
Operating temperature:
Maximum ambient operating temperature:
Hygrometry:
Dimension:
Weight:
PAGE 54
Internal CE / UL / CSA / IEC 950 (130W).
Input : 100 VAC to 240 VAC ; 50-60Hz ; I = 3A Max.
-25 °C to +85 °C (-13 °F to +185 °F).
0 °C to 50 °C (32 °F to 122 °F).
< 40 °C ( < 104 °F).
10% to 80% (without condensation).
W 480 x D 420 x H 133 mm / 19"W x 16.5"D x 5.25"H.
(Compatible with a Standard 19" rack, Height = 3 U).
NTX8022A: 8 kg / 17,6 lbs (without option).
