Chapter 6 : NATIX™ & REMOTE KEYPAD LCD SCREEN DESCRIPTION (continued)
6-5. LCD FUNCTIONS DESCRIPTION (continued)
2-3 [output sync] + ENTER.
Select an output between OUT 1 & OUT 2 with
Select the Output Sync. type with
• [H&V] = H & V Separate Sync.
• [COMP] = Composite Sync.
• [SOG] = Sync On Green.
2-4 [type of screen] + ENTER.
Select an item with
• [4/3] = If your image is displayed on a 4/3 wall mounted projection screen shape.
• [16/9] = If your image is displayed on a 16/9 wall mounted projection screen shape.
NOTE: Available only in case of 4/3 output format.
2-5 [test pattern] + ENTER.
Select an output between OUTPUT 1 & OUTPUT 2 with
Select an item with
• [no pattern] = No test pattern is displayed.
• [centering] = Displays onto the output a centering pattern (for position and size adjustments).
• [color bar] = Displays onto the output a color bar pattern.
• [grid] = Displays onto the output a grid pattern.
• [grey scale] = Displays onto the output a grey scale pattern.
• [multi-burst] = Displays onto the output a multi-burst pattern.
• [softedge] = Displays onto the output a softedge pattern.
2-6 [video output] + ENTER. (This menu is available with the OPT-iX-SDTVD1 option only).
NOTE: The following functions act on the optional video outputs only (Composite video, S.VIDEO, YUV and SDI).
2-6-1 [video standard] + ENTER.
Select the output standard for the video outputs with
• [NTSC] = NTSC for composite and S.VIDEO outputs. 60Hz frame rate for YUV & SDI outputs.
• [PAL] = PAL for composite and S.VIDEO outputs. 50Hz frame rate for YUV & SDI outputs.
• [NTSCj] = Japan NTSC for composite and S.VIDEO outputs. 60Hz frame rate for YUV & SDI outputs.
2-6-2 [output rate] + ENTER.
Select a function with
• [internal] = The video output rate is generated by the device depending of the selected video standard.
• [input # X] = The video output rate is synchronized onto an input of your choice (video source only).
NOTE:
2-6-3 [flicker adj.] + ENTER.
Select a level of anti-flicker with
2-6-4 [U/Over scan] + ENTER.
Select a function with
• [underscan] = The entire image is visible on the screen. Computer display mode is underscan.
• [overscan] =
2-6-5 [pos settings] + ENTER.
Adjust the video image position with the following functions:
• [size] = Adjust the Horizontal & Vertical size with H and V knobs.
• [position] = Adjust the Horizontal & Vertical position with H and V knobs.
2-6-6 [input stab.] + ENTER.
This function allows to improve the input stability of the referenced input. Select the type of the referenced
source between DVD & VCR.
2-6-7 [color tracking] + ENTER.
This function allows to improve the image color (act only if input stab. = VCR).
2-7 [output status] + ENTER.
PAGE 34
+ ENTER.
+ ENTER.
+ ENTER between:
If the device is already set in follow mode (LCD menu # 3-2 = follow...). This input and the
input used for the follow mode should be the same.
+ ENTER between:
The image is displayed about 8 % bigger than in underscan mode, to avoid seeing the
corners and the borders. Standard TV display mode is overscan.
+ ENTER.
+ ENTER.
+ ENTER.
+ ENTER between:
+ ENTER.
