Chapter 6 : NATIX™ & REMOTE KEYPAD LCD SCREEN DESCRIPTION (continued)
6-5. LCD FUNCTIONS DESCRIPTION (continued)
6 [AUDIO OUT 1] + ENTER.
The following commands allow controlling the AUDIO output 1.
6-1 [master volume] + ENTER.
Adjust the audio output level with
6-2 [audio mode] + ENTER.
Select the output audio mode with
• [mono] =
• [stereo] = Set the output in stereo mode.
6-3 [audio source] + ENTER.
Select an item with
• [auto follow] = The audio follows the video image.
• [input --] =
6-4 [audio level] + ENTER.
This function allows to separately adjusting the level of each audio input. Adjust the level with
NOTE: This function acts on the selected (diffused) audio input.
6-5 [audio balance] + ENTER.
This function allows adjusting for each input the audio balance. Adjust the level with
NOTE: This function acts on the selected (diffused) audio input.
6-6 [AUX input] + ENTER.
Auxiliary input for mixing with the diffused source.
6-7 [mute off] + ENTER.
Switch ON or OFF the audio output. Validate with ENTER.
7 [AUDIO OUT 2] + ENTER.
The following commands allow controlling the AUDIO output 2.
7-1 [master volume] + ENTER.
Adjust the audio output level with
7-2 [audio mode] + ENTER.
Select the output audio mode with
• [mono] =
• [stereo] = Set the output in stereo mode.
7-3 [audio source] + ENTER.
Select an item with
• [auto follow] = The audio follows the video image.
• [input --] =
7-4 [audio level] + ENTER.
This function allows to separately adjust the level of each audio input. Adjust the level with
NOTE: This function acts on the selected (diffused) audio input.
7-5 [audio balance] + ENTER.
This function allows adjusting for each input the audio balance. Adjust the level with
NOTE: This function acts on the selected (diffused) audio input.
7-6 [AUX input] + ENTER.
Auxiliary input for mixing with the diffused source.
7-7 [mute off] + ENTER.
Switch ON or OFF the audio output. Validate with ENTER.
PAGE 38
Set the output in mono mode.
+ ENTER:
The selected audio input (is permanently diffused).
Set the output in mono mode.
+ ENTER:
The selected audio input (is permanently diffused).
+ ENTER.
+ ENTER.
+ ENTER.
+ ENTER.
NATIX™
+ ENTER.
+ ENTER.
+ ENTER.
+ ENTER.
