NATIX™

Chapter 4 : UPDATING

™
The NATIX can be update thanks a COMPUTER (PC) via its REMOTE (RS-232) connector.

4-1. CONNECTIONS

Connect the "REMOTE CONTROL RS-232" connector of the device to the SERIAL port of your COMPUTER
with a DB9 M/F straight cable.
Connect the device to an AC power outlet.
Switch OFF the device (rear panel switch = O).

4-2. UPDATE INSTRUCTIONS

Open the file "iX updater" (in start/Program/ANALOG WAY/iX8022).
Click on "START" on the SOFTWARE.
Switch ON the device. The POWER LED blinking slowly and the update will start.
When the software displays "Program operation completed", SWITCH OFF and ON the device with the rear panel
switch.
Click on the "QUIT" button to close the update software.
NOTE: Your NATIX
NOTE: The updater files are available on our web site: http://www.analogway.com
™
is now ready to work.
Figure 20: Updating.
PAGE 25
