NATIX™
7-4. COMMANDS AND RESPONSES TABLE (continued)
ASCII RESPONSE
COMMAND
STATUS COMMANDS
U UNIT
IL ILD
il ild
ID IFD
id ifd
IP IPS
ip ips
IH IHP
ih ihp
IV IVP
iv ivp
IK IST
ik ist
II IIN
ii iin
IO IOO
io ioo
IF IFA
if ifa
XA REFA
xa refa
XF REFF
xf reff
XT REFT
xt reft
NOTE:
COMMAND
DESCRIPTION
Measures unity in tens of kHz.
Horizontal period of input signal (M)
Horizontal period of input signal (P)
Vertical period of input signal (M)
Vertical period of input signal (P)
Input Sync. detection (M).
Input Sync. detection (P).
Sign of the horizontal input Sync. (M)
Sign of the horizontal input Sync. (P)
Sign of the vertical input Sync. (M)
Sign of the vertical input Sync. (P)
Input Sync type detection (M).
Input Sync type detection (P).
Interlaced signal detection (M).
Interlaced signal detection (P).
"Out of range" signal detection (M).
"Out of range" signal detection (P).
Standard input signal detection (M).
Standard input signal detection (P).
Synchronized input (M).
Synchronized input (P).
Synchronized input standard (M).
Synchronized input standard (P).
Frame frequency of the synchronized
input (M).
Frame frequency of the synchronized
input (P).
(M) = output 1.
(P) = output 2.
Chapter 7 : REMOTE CONTROL PROGRAMMER'S GUIDE (continued)
TYPE
MIN MAX
0 65535 ex: 14500 = 145 MHz
Rd
Rd 0 65535 Line frequency (in kHz) = (UNIT VALUE)x10
÷ (ILD VALUE).
Rd 0 65535 Line frequency (in kHz) = (UNIT VALUE)x10
÷ (ild VALUE).
Rd 0 65535 Frame frequency (in Hz) = (Line frequency in
Hz) ÷ (IFD VALUE).
0 65535 Frame frequency (in Hz) = (Line frequency in
Rd
Hz) ÷ (ifd VALUE).
Rd 0 1 0 = no Sync. detected
0 1 0 = no Sync. detected
Rd
Rd 0 1 0 = negative
Rd 0 1 0 = negative
0 1 0 = negative
Rd
Rd 0 1 0 = negative
Rd 0 3 0 = Separate H &V sync.
1 = Composite sync. (TTL).
2 = SOG (Sync. On Green).
Rd 0 3
3 = Composite sync. (analog).
0 1 0 = not interlaced
Rd
Rd 0 1 0 = not interlaced
Rd 0 1 0 = In range
Rd 0 1 0 = In range
Rd 0 29 0 = no signal
1 = wrong signal
2 = NTSC std (3.58/60) 17 = XGA
3 = PAL std (4.43/50)
4 = SECAM (50Hz)
5 = B&W (50Hz)
6 = B&W (60Hz)
7 = YUV 50Hz
Rd 0 29
8 = YUV 60Hz
9 = RGB 50Hz
10 = RGB 60Hz
11 = VGA1 350L
12 = VGA2 400L
13 = VGA3 480L
14 = PLASMA 42"
0 8
Rd
Identical as XR command.
Rd 0 8
Rd 0 29
Identical as XF command.
0 29
Rd
Rd 0 65535 Value in hundredth of Hz.
Rd 0 65535 Value in hundredth of Hz.
Rd/Wr = Read and write command.
Rd = Read only command.
VALUE
DESCRIPTION
1 = Sync. detected.
1 = Sync. detected.
1 = positive.
1 = positive.
1 = positive.
1 = positive.
1 = interlaced.
1 = interlaced.
1 = Out of range.
1 = Out of range.
15 = SVGA
16 = MAC
18 = PLASMA 50'
19 = MAC 21'
20 = SXGA
21 = UXGA
22 = SXGA+
23 = DILA 4/3
24 = DILA16/9
25 = 1080i 50Hz
26 = 1080i 60Hz
27 = 480p 60Hz
28 = 720p 50Hz
29 = 720p 60Hz
PAGE 45
