Chapter 3 : OPERATING MODE (continued)

3-3. OPERATING WITH THE REMOTE KEYPAD

3-3-1. COMMUNICATION SETUP
• CASE OF RS-232 PORT
Connect the REMOTE KEYPAD to the NATIX
Then only power ON all the devices.
Activate the REMOTE KEYPAD RS232 communication port with the LCD of the REMOTE KEYPAD
(CONSOLE > RS232/LAN port > RS232).
• CASE OF LAN PORT
Connect the REMOTE KEYPAD to the NATIX
LAN communication port of the NATIX™ with the REMOTE KEYPAD LCD menu (CONTROL > LAN
setup).
Select the LAN communication port of the NATIX
LAN).
Connect the LAN port (RJ45 connector) of the NATIX
Connect the LAN port (RJ45 connector) of the REMOTE KEYPAD to your network according to your
installation.
Then configure the REMOTE KEYPAD LAN communication port with the LCD menu (CONSOLE > LAN
setup).
Activate the REMOTE KEYPAD LAN communication port with the LCD menu (CONSOLE > RS232/LAN
port > LAN).
PAGE 22
™
according to your installation (see section 2-3-1. )
™
with the RS-232 port as indicated above, then configure the
™
with the LCD menu (CONSOLE > RS232/LAN port >
™
to your network according to your installation.
