6-5. LCD FUNCTIONS DESCRIPTION

1 [INPUT] + ENTER.
1-1 [input type] + ENTER.
Select an input with
Select the input signal type with
• [SDTV Composite]
• [SDTV S.VIDEO]
• [SDTV YUV]
• [SDTV RGBS TTL]
• [SDTV RGB SOG]
• [Computer DVI] = optional DVI input.
Then for [SDTV Composite], and [SDTV S.VIDEO], select the video standard with
• [NTSC / PAL / SECAM] = automatic NTSC, PAL, and SECAM standard detection.
• [NTSC] = NTSC standard detection only.
• [SECAM] = SECAM standard detection only. • [B & W 50/60 Hz] = Black and White standard detection.
1-2 [used input] + ENTER.
Select an input and then select an item with
• [used] = A signal is connected to the input.
• [unused] = No signal is connected to the input. The input is unused.
1-3 [H sync load] + ENTER.
Select for each input the load of the H Sync. with
1-4 [VCR mode] + ENTER.
This function allows improving the image contour of low quality VHS tapes. Select [on] with ENTER.
1-5 [input status] + ENTER.
Indicates the status of the selected input.
2 [OUTPUT #] + ENTER.
2-1 [output format] + ENTER.
Select one of the following output format with
• [WVGA:852x480]
• [SVGA:800x600]
• [XGA:1024x768]
• [SXGA:1280x1024]
• [SXGA+:1400x1050]
• [D-ILA - 4/3]
• [D-ILA - 16/9]
• [HDTV 720p]
NOTE: For fixed pixels display devices (DMD, LCD, PLASMA...), always select the output format corresponding
to the native resolution of the display device. Thus, the display device will not have to scale the image and
the result will be better.
2-2 [output rate] + ENTER.
Select an output rate between:
• [internal 50Hz] =
• [internal 60Hz] =
• [internal 72Hz] =
• [internal 75Hz] =
• [follow] =
Chapter 6 : NATIX™ & REMOTE KEYPAD LCD SCREEN DESCRIPTION (continued)
+ ENTER.
+ ENTER between:
The output frame is generated at 50 Hz by the device.
The output frame is generated at 60 Hz by the device.
The output frame is generated at 72 Hz by the device.
The output frame is generated at 75 Hz by the device.
The output frame is synchronized onto one input signal. Select the needed input with
and validate with ENTER.
• [SDTV RGBS ana.]
• [Computer SOG]
• [Computer HV/C]
• [HDTV] = HDTV input format (720p and 1080i).
• [SDTV SDI] = optional SDI input.
• [PAL] = PAL standard detection only.
+ ENTER between:
+ ENTER.
+ ENTER.
+ ENTER between:
