NATIX™

2-2. CONNECTING A CONTROL DEVICE FOR USING THE REMOTE CONTROL SOFTWARE

™
Your NATIX is shipped with a Windows 95 or later compatible Remote Control Software (3.5" disk). This software
allows you to control and make all adjustments by a simple mouse click.
NOTE: Preferably use Windows NT, 2000, or XP for LAN operation.
2-2-1. CONNECTING TO THE RS-232 PORT
- Connect the serial port of your control device to the RS-232 port (DB9 Female connector) of the NATIX
straight cable (DB9 Female / DB9 Male).
- Speed transmission: 9600 bauds, 8 data bits, 1 stop bit, no parity bit, no flow control.
- Pin-out:
PIN #
2
3
5
2-2-2. CONNECTING TO THE LAN PORT
- Connect the LAN port (RJ45 connector) of the NATIX

2-3. CONNECTING THE REMOTE KEYPAD

2-3-1. CONNECTING TO A NATIX
Turn OFF your NATIX
Connect the RS-232 connector (DB9 female) of your NATIX
KEYPAD with the supplied DB9 M/F cable.
Turn ON your NATIX
NOTE: The REMOTE KEYPAD is powered by the NATIX
2-3-2. CONNECTING TO A NETWORK (LAN)
Connect the power supply to a power outlet and to the DC-IN connector (rear panel).
Connect the REMOTE KEYPAD to your network according to your installation.
FUNCTIONS
TRANSMIT DATA (Tx)
RECEIVE DATA (Rx)
GROUND (Gnd)
™
WITH THE RS-232 PORT
™
(rear panel switch).
™
(REAR panel switch).
DB9 female (Rear panel of the NTX8022)
™
to your network according to your installation.
™
to the DB9 male connector of the REMOTE
™
via its DB9 (RS-232) connector.
Figure 11
Figure 12
Chapter 2 : CONNECTING (continued)
™
with a
PAGE 15
