Quick Start

During Setup and Programming:
Press the UP or DOWN buttons to modify the selection.
Press the MODE button to advance and confirm through the setup steps.

Selecting the Heat or Cool Mode

Select mode by pressing the MODE button.
Heating Only - The HEAT setting indicates the temperature the room has to reach
before the furnace will turn on to heat the room.
Cooling Only - The COOL setting indicates the temperature the room has to reach
before the air conditioner will turn on to cool the room.
Heating or Cooling (Auto-Changeover) - AUTO will automatically select heat or cool
based on room temperature demand.
OFF - OFF indicates both heating and air conditioning systems are turned off.
Selecting Your Desired Temperature
AUTO-CHANGEOVER MODE - Pressing the UP or DOWN buttons in Auto mode
will adjust both the heat and cool setpoints simultaneously. To adjust heat and cool
setpoints individually, choose HEAT mode to adjust the heat setpoint and COOL
mode to adjust the cool setpoint, then return to AUTO mode.
HEAT OR COOL MODE - Pressing the UP or DOWN buttons in Heat or
Cool mode will adjust only the heat or cool setpoints individually displayed.
NOTE - This thermostat has a fixed two degree deadband. With a Cool setpoint of
72 degrees Fahrenheit, cooling will energize at a room temperature of 74 degrees.
With a Heat setpoint of 68 degrees Fahrenheit, heating will energize at 66 degrees.
Using the Reset Filter Button
Reset Filter - Press the RST FILTER button to view the current filter
runtime. Press the OUTDOOR button to reset the filter runtime counter
to 0. Press the RST FILTER button again to return to normal operation.
