Quick Start

During Setup and Programming:
Press the UP or DOWN buttons to modify the selection.
Press the MODE button to advance and confirm through the
setup steps.
Setting the Clock and Day
Press the SET
CLOCK button.
Adjust the clock
using the UP or
DOWN buttons. Press MODE to advance to the day setting.
Adjust the day using the UP or DOWN buttons. Press the SET
CLOCK button to confirm settings.
TIP: To adjust the time by hours press and hold the OUTDOOR
button while pressingthe UP or DOWN buttons.
Selecting the Heat or Cool Mode
Select mode by pressing the MODE button.
Heating Only – The HEAT setting indicates the
temperature the room has to reach before the furnace
will turn on to heat the room.
Cooling Only – The COOL setting indicates the temperature
the room has to reach before the air conditioner will turn on to
cool the room.
Heating or Cooling (Auto-Changeover) – AUTO will
automatically select heat or cool based on room temperature
demand.
OFF–OFF indicates both heating and air conditioning systems
are turned OFF.
Selecting Your Desired Temperature
Auto-Changeover Mode – Pressing the UP or DOWN buttons
in Auto or Program mode will adjust both the heat and cool
setpoints simultaneously. To adjust heat and cool setpoints
individually, choose HEAT mode to adjust the heat setpoint
and COOL mode to adjust the cool setpoint, then return to
AUTO mode.
Heat or Cool Mode – Pressing the UP or DOWN buttons in
Heat or Cool mode will adjust only the heat or cool setpoints
individually displayed.
www.DaikinApplied.com
7-D P
ay rogrammable
Using the Override Button
Unoccupied Operation – During programmed,
unoccupied periods, pressing the OVERRIDE button
will force the thermostat into Occupied 1 settings for
30 minutes. Each press of the OVERRIDE button
will add another 30 minutes of time for up to 4 hours. If the
maximum time has been set, the next press of the OVERRIDE
button will reset the timer and return the thermostat to the
correct time period program for the day.
Occupied Operation – During programmed, occupied periods,
pressing the OVER-RIDE button will force the thermostat into
an unoccupied period for the rest of the day. During this forced
unoccupied period the OVERRIDE button will operate as
described above.
NOTE: Override may only be used when the thermostat is
set to PROGRAM ON.
Viewing the Outdoor Temperature Sensors
Outdoor Temp – Press the OUTDOOR button to
view the current outdoor temperature. The high and
low temperatures for the day will also be displayed.
The high and low temperatures reset at 12:00 am.
Press the OUTDOOR button again to display POOL or SPA
temperature sensors. Keep pressing the OUTDOOR button to
return to normal operation.
NOTE: If no outdoor sensor is connected, 2 dashes [- -] will
appear with the first button press.
