Quick Start

Using the Override Button

Unoccupied Operation - During a Dry Contact forced unoccupied period pressing the
OVERRIDE button will force the thermostat into the mode it was in before the Dry
Contact forced it into the Unoccupied mode. For example: if the thermostat was in the
Auto mode and the Dry Contact forced it into Unoccupied mode, pressing OVERRIDE
will force the thermostat back into the Auto mode. The remaining override time will be
displayed in the upper left corner of the display. Each press of the OVERRIDE button
will add another 30 minutes of time for up to 4 hours. If the maximum time has been
set, the next press of the OVERRIDE button will reset the timer and return the
thermostat to the Unoccupied mode.
Viewing the Outdoor and Remote Temperature Sensors
OUTDOOR TEMP - Press the OUTDOOR button to view the current
outdoor temperature. Pressing the OUTDOOR button again to return
to normal operation.
Note: If no outdoor sensor is connected, 2 dashes [- -] will appear with
the first button press.
REMOTE TEMP - Press the ACCESSORY button to enter the accessory
setup screen. Press the UP button to view linked wireless and wired
sensors and other accessories. Press the ACCESSORY button to
return to the main screen.
Viewing and Setting the Indoor Humidity Sensor
IMPORTANT: Allow at least 2 minutes after the thermostat
is powered on for the humidity to read correctly.
Press the HUMIDITY button to display the current humidity measured at
the thermostat. The room relative humidity is displayed in the top left corner.
The humidification setpoint appears in the larger center display and can be
adjusted using the UP or DOWN buttons. Press the MODE button to view and
adjust the dehumidification setpoints. Press the HUMIDITY button again to
confirm settings and return to normal operation.
Note: Due to variations in environmental conditions, it is not always
possible to achieve the desired humidification or dehumidification
setpoint.
14 8/29/13
NOTE: Override may only be
used when the Dry Contact
has forced the thermostat
into the Unoccupied mode.
PAGE 6
