- Page 1 TSTATD2100-2 RESIDENTIAL Digital Thermostat Heat Pump • Non-Programmable Owner's Manual Installation Instructions Residential Use...
-
Page 2: Table Of Contents
Table of Contents Safety Warnings ..............3 Front Panel ................4 Dispay ..................5 Normal Operation ..............6 Aux Heat .................7 Fahrenheit or Celsius ............8 Preparation ................9 Remove Old Thermostat .............10 Battery Replacement ............11 Wire Connections ..............12 Sample Wiring Diagrams ...........13 Test Operation ..............17 Troubleshooting ..............19 Warranty ................20... -
Page 3: Safety Warnings
Safety Warnings Follow Installation Instructions carefully. DISCONNECT POWER TO THE HEATER - AIR CONDITIONER BEFORE REMOVING THE OLD THERMOSTAT AND INSTALLING THE NEW THERMOSTAT. The two Alkaline “AA” batteries must be replaced at least once every 12 months to ensure proper operation. The Low Battery icon will appear on the display when it is time to replace the batteries. -
Page 4: Front Panel
Front Panel FAN SWITCH DISPLAY On or Auto AUX HEAT HEAT AUTO NORM EMRGC’Y LOCKOUT COOL HEAT BATTERIES BATTERY DOOR COOLER & MODE SWITCH WARMER Cool, Off, or Heat BUTTONS BI-COLOR LED Heat or Cool demand indicator when system powered: Red = Heat Green = Cool... -
Page 5: Dispay
Display SET TEMP HEAT COOL BATTERY Heat and Cool indicators. In normal operation, Heat or Cool appears, depending on the Mode Switch position. When heat or cool is energized, the Heat or Cool indicator will flash. Current room or set temperature. Desired set temperature indicator. -
Page 6: Normal Operation
Normal Operation FAN SWITCH On or Auto AUX HEAT HEAT AUTO NORM EMRGC’Y LOCKOUT COOL HEAT BATTERIES COOLER & WARMER MODE SWITCH Cool, Off, or Heat BUTTONS Operation Select Cool or Heat with the Mode Switch. Normally leave the fan switched to Auto. In Fan Auto, the fan will turn on only with a heat or cool demand. -
Page 7: Aux Heat
Aux Heat AUX HEAT HEAT AUTO NORM EMRGC’Y LOCKOUT AUX HEAT SWITCH COOL HEAT BATTERIES Emergency - Disables all compressor functions* and energizes only Aux Heat to satisfy the heat demand. Normal - Aux Heat is allowed to run, if necessary, along with the heat pump to satisfy the heat demand. -
Page 8: Fahrenheit Or Celsius
Fahrenheit or Celsius AUX HEAT HEAT AUTO NORM EMRGC’Y LOCKOUT COOL HEAT BATTERIES COOLER & WARMER MODE SWITCH BUTTONS Cool, Off, or Heat Operation Select Off with the Mode Switch. Press and hold the COOLER and WARMER buttons at the same time until the temperature is displayed in degrees Celsius. -
Page 9: Preparation
Preparation • Proper installation of the thermostat will be accomplished by following these step by step instructions. If you are unsure about any of these steps, call a qualified technician for assistance. • These tools will be required: Wire Cutter Flat Blade &... -
Page 10: Remove Old Thermostat
Remove & Replace Old Thermostat • Remove the cover of the old thermostat. If it does not come off easily check for screws. • Loosen the screws holding the thermostat base or subbase to the wall, and lift away. • Disconnect the wires from the old thermostat. Tape the ends of the wires as you disconnect them, and mark them with the letter of the terminal for easy reconnection to the new thermostat. -
Page 11: Battery Replacement
Battery Replacement The batteries are easily accessible from the battery door located on the bottom front of the thermostat (fig. 1). To open the battery slot, pull out on the battery door (fig. 1) and swing down (fig. 2). FIG. 1 FIG. -
Page 12: Wire Connections
(Energize to Heat) Rev. Valve (Energize to Cool) Thermal Insulating Sheet A label is provided on the backplate that prevents drafts originating inside MODEL: TSTATD2100-2 the wall from entering the thermostat. 97061606 4Z95 USE SIZE “AA” MADE IN CHINA ALKALINE BATTERIES These drafts, left unchecked, may cause incorrect room temperature readings. -
Page 13: Sample Wiring Diagrams
Sample Wiring Diagrams 4 Wire, 1 Stage Cooling, 1 Stage Heat-Heat Pump with O reversing valve. Residential Heat Pumps, split systems & package units, with no auxiliary heat. Common wire optional C R Y W G B O 4 Conductor 18 to 22 gauge unshielded cable from the thermostat to the equipment. - Page 14 Sample Wiring Diagrams 5 Wire, 1 Stage Cooling, 2 Stage Heat-Heat Pump with O reversing valve. Residential Heat Pumps, split systems & package units, with auxiliary heat. Common wire optional C R Y W G B O 5 Conductor 18 to 22 gauge unshielded cable from the thermostat to the equipment.
- Page 15 Sample Wiring Diagrams 4 Wire, 1 Stage Cooling, 1 Stage Heating-Heat Pump with B reversing valve. Residential Heat Pumps, split systems & package units, with no auxiliary heat. Common wire optional C R Y W G B O 4 Conductor 18 to 22 gauge unshielded cable from the thermostat to the equipment.
- Page 16 Sample Wiring Diagrams 5 Wire, 1 Stage Cooling, 2 Stage Heat-Heat Pump with B reversing valve. Residential Heat Pumps, split systems & package units, with auxiliary heat. Common wire optional C R Y W G B O 5 Conductor 18 to 22 gauge unshielded cable from the thermostat to the equipment.
-
Page 17: Test Operation
Test Operation • Turn on the power to the Heat Pump. • On the thermostat, slide the Mode Switch to HEAT. Press the COOLER or WARMER button until the set temperature is 10 degrees above room temperature. The HVAC unit should energize in the heating mode. Note: You may need to wait up to five minutes for heating to energize due to the compressor lockout feature. - Page 18 Test Operation • On the thermostat, slide the Mode Switch to COOL. Press the COOLER or WARMER button until the set temperature is 10 degrees below room temperature. The HVAC unit should energize in the cooling mode (Page 6). Note: You may need to wait up to five minutes for cooling to energize due to the compressor lockout feature.
-
Page 19: Troubleshooting
Troubleshooting • SYMPTOM: The slide switches on the thermostat are very difficult to move. CAUSE: The backplate of the thermostat is screwed too tightly into a wall that is not perfectly flat. REMEDY: Loosen the screws holding the thermostat into the wall. •... -
Page 20: Warranty
Installer Name __________________________________________________________________ Installation Date ________________________________________________________________ Model # _______________________________________________________________________ Serial # ________________________________________________________________________ For further information about this warranty, contact Daikin Consumer Affairs at (877) 254-4729 or by mail to 7401 Security Way, Houston, Texas 77040. - Page 21 Battery Stat P/N TSTATD2100-2 Tested to Comply with FCC Standards FOR HOME OR OFFICE USE 4Z95 Printed on recycled paper. P/N 88-995 Rev. 1 12/13...
