Installation Instructions:
This thermostat has a diagnostic feature that enables testing of all
outputs. This feature is contained in Technician Setup.
To enter Technician Setup, press and hold the SETUP button for 5 seconds until
all the icons appear. Follow the next steps to view settings and test equipment.
1.
Press MODE to view the version numbers of the thermostat.
2.
Press MODE again to view the jumper settings and current state of
the Dry Contact terminals.
3.
Press MODE again and the scrolling display will read "TURN ON
EQUIPMENT?" Press UP for Yes or DOWN for No.
If Yes is chosen, press UP to turn on heat or DOWN to turn on
Cooling. The scrolling display will read "NOTHING ON. " Next:
Press UP to turn on and cycle up through the heating stages.
Press DOWN to turn the heating stages off. Press MODE to exit.
Press DOWN to turn on and cycle down through the cooling stages.
Press UP to turn the cooling stages off. Press MODE to exit.
4.
Press MODE until "CALIBRATE SENSORS?" appears on the scroll-
ing display. Press UP for Yes or DOWN for No. Press MODE to
select which sensor to calibrate. Use UP or DOWN to modify your
selection.
5.
Press MODE until "CONTROL HUM?" appears on the scrolling dis-
play. Press UP for On or DOWN for Off. Press MODE to continue.
6.
Press MODE until "CONTROL DEHUM?" appears on the scrolling
display. Press UP for On or DOWN for Off. Press MODE to
continue.
To exit Technician Setup at any time, press the SETUP button. Technician Setup
will automatically exit after 10 minutes if no buttons are pressed.
