Built-in SNMP card and MODBUS card located at the rear of the touch panel provide
network communication and MODBUS communication respectively. Besides, the SNMP
card allows remote monitoring, management and event log download of the UPS. For
relevant location and information, please refer to Figure 4-17 and Page 4-15.
Built-in USB ports (
UPS, touch panel, power modules, system control card and parallel communication
refer to Page 4-17 and Page 4-15.
Built-in SRAM records at maximum 10000 event logs.
10-inch graphic and color touch panel enables users to easily operate the UPS and un-
derstand the UPS status.
Fan speed auto adjustment prolongs fan life and reduces noise when the critical loads
decrease. Moreover, fan failure detection circuit is established.
State-of-the-art microprocessor technology performs self-detection and monitors fan
speed in real time, which provides complete and detailed operating status of the UPS.
2.4

Exterior and Dimensions

Modulon DPH Series
) located at the rear of the touch panel allow upgrade of the
600
mm
(Figure 2-1: Exterior & Dimensions)
2-6
2000
mm
1100
mm
