No.
4. If there is any damage or anything missing, please immediately contact the dealer
from whom you purchased the unit.
5. If the UPS needs to be returned, carefully repack the UPS and all of the accessories
using the original packing material that came with the unit.
2.3 Functions & Features
Hot swappable STS module, communication interfaces and power modules (optional)
realize on-line maintenance, reduce the MTTR (Mean Time to Repair) and expand sys-
power contamination.
Output power factor=1.
Automatic input frequency detection enables operation at 40Hz ~70Hz.
Automatic restart
1. The UPS will restart in normal mode automatically right after the AC line resumes
following a low battery shutdown.
2. The UPS returns automatically to normal mode from bypass mode after an overload
condition is cleared.
Automatically detects whether bypass voltage is out of rating voltage (default: voltage
±15% & frequency ±3Hz). If yes, the UPS will stop supplying power to the critical loads
to protect your electronic equipment.
Modulon DPH Series
4-Pin Dry Contact Terminal Block
(used for REPO dry contacts; please refer to
12
Figure 4-3)
6-Pin Dry Contact Terminal Block
(used for MODBUS and BMS ports located at the
13
rear of the touch panel; please refer to Figure 4-17)
8-Pin Dry Contact Terminal Block
(used for (1) external battery temperature dry
14
contacts and (2) external switch/ breaker status dry
contacts; please refer to Figure 4-3)
10-Pin Dry Contact Terminal Block (used for input
15
and output dry contacts; please refer to Figure 4-3)
Item
2-4
Q'ty
1 PC
1 PC
2 PCS
2 PCS
