Delta Modulon DPH series User Manual page 77

No. Item
RESET
1
MODBUS
2
(Built-in MODUBS card)
BMS
3
DISPLAY
4
EMS/ CONSOLE
5
6
(USB Ports)
7
(Built-in SNMP card)
Press the RESET button once to restart the LCD.
1. Lets the UPS have MODBUS communication
function.
2. Connects to a user-supplied monitoring system.
Connects to the Delta battery management system
(optional). The BMS port application is only applicable to
sealed lead-acid batteries. Please refer to 7.10.4 Battery
& Charging Setting.
Before shipment, the DISPLAY port has been
connected to the display port show in Figure 4-3 with the
designated cable in Delta factory.
Connects to a user-supplied environmental monitoring
system or Delta EnviroProbe 1000 (optional).
There are two USB ports. Connects a user-supplied USB
1. Lets the UPS have network communication function.
2. Connects to a user-supplied monitoring system.
4-15
4 Communication Interfaces
Function
